A BUCKET-strainer has the advantage of being able to be installed in either a horizontal or vertical position. However, in both cases, the screening element or "leg" must be on the "downside" of the strainer body so the entrapped solids can be properly collected and held for disposal. Eaton heavy-duty Model 85 Y Strainers are furnished with high quality stainless steel screens that are carefully fabricated to fit the strainer body perfectly. This, coupled with the precision machined screen seat on the body of the strainer, protects against any bypass.
Features
- Heavy Duty Construction
- Compact design
- Bolted or threaded covers
- Standard stainless steel screens
- Suitable for liquid, gas or steam
- Monel screens
- Perforated stainless steel screens - 1/32 to 1/2
- 20, 40, 60, 80, 100, 150, 200, 325 and 400 mesh stainless steel screens
| Carbon Steel and Stainless Steel - Threaded, Socket Weld & Flanged | ||||
|---|---|---|---|---|
| Size | Material | End Connections | Cover | Rating (WOG) - Non Shock |
| 1/4" to 2" | Carbon Steel | Threaded or Socket 600# | Threaded | 1480 psi @ 100F |
| Stainless Steel | 1440 psi @ 100F | |||
| 1/2" to 10" | Carbon Steel | Flanged 150# | Bolted | 285 psi @ 100F |
| Flanged 300# | 740 psi @ 100F | |||
| Stainless Steel | Flanged 150# | 275 psi @ 100F | ||
| Flanged 300# | 720i @ 100F | |||
Applications
Y strainers are engineered to withstand the most aggressive industrial and commercial, steam and gas applications. Available in carbon steel or stainless steel for pipeline sizes from 1/4" to 10", with threaded, flanged, or socket weld connections.
- Chemical processing
- Petroleum
- Power generation
- Marine
- Water
- Oil & Gas
- Offshore
- Iron & Steel
- Automotive
- HVAC
- Pulp & Paper
- Food & Beverage
- Pharmaceutical
