Globe Type Single Seat Top - Bottom Guide

Flow-Tek control valve is a high-performance, general application valve coupled with the high-thrust Flow Act pneumatic diaphragm actuator. The modular design allows by using the same body with different types of bonnets, trims and actuators, the reduction of spare parts and offers an interchangeable valve for a broad range of industries and applications. The Flow-TEK valve is capable of operating within temperature ranging from -196°C up to +538°C (-321°F up to +1000°F) according to the selected material.

Request A Quote Download Catalogue
  • Description

Precise machined plug contours and long stroke lengths results in an excellent control performance. Easy upgrade from standard trims to low noise- or cavitations control trims. Up to 9 kvs/cv-values available per size, allows a wide range of process conditions for each size.

The Flow-TEK control valve offers a sturdy plug head guide for minimizing vibrations and wear. Due to the design of a profile-ring - very reliable sealing between body and seat, easy maintenance, no machining required of the body seat area when changing the seat.

Features

  • Modular design
  • Standardized low noise- and cavitations control trims
  • Profile-ring sealing between body and seat
  • Angle- and 4 Flange body design available
  • Heavy duty design for electrical rotary actuators in power plants
  • Short delivery times

Applications

  • Water works.
  • Oil and Gas
  • Power plants.
  • Sewage plants.
  • Process industries.
  • Chemical and petrochemical plants.
