Low Pressure Reducing Valve

Flow-Tek Balanced Plug Gas Pressure Regulator is the ideal valve for low pressure gas regulation with higher inlet pressures. The self-contained, low-pressure gas regulator is for use on tank blanketing, gas meter inlet pressure regulating, gas burners and other low-pressure air and gas applications. The valve has a 360° orientation, can be installed in any position, and can be easily repositioned while in line. The seat and plug can be inspected without removing body from the line.

Applicable Standard

  • Design Standard : MFG. STANDARD
  • Face to Face : MFG .STANDARD
  • End Connection : Flanged End to suit ANSI / DIN / BS / JIS / IS etc.
  • Testing Standard : API 598 / CONTROL VALVE ANSI-FCI-70-2-2006 STD
Request A Quote Download Catalogue
  • Description

Features

  • Inlet pressures up to 150 psi (10 bar)
  • Rugged, heavy-duty design allows emergency outlet pressure to reach 100% on inlet pressure without damaging valve
  • Completely Self-Operated - No external power source required
  • Soft elastomer plug provides ANSI Class VI shutoff
  • Easy to inspect and maintain - Seat and plug can be inspected without removing body from the line
  • Completely self-operated. No external power source required
  • Wide range of low back-pressure settings - Choose from six pressure ranges for set points ranging from 1 w.c. to 7 psi (3mbar to 0,5 bar)
  • Soft elastomer plug provides ANSI Class VI shutoff

Applications

  • Air, Nitrogen, Natural Gas, Hydrogen and many other Industrial Gases. Sewage plants.
  • Process industries.
